| Author |
Mini SuperMode for K550/W610 |
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
Mini SuperMode for K550/W610Mini SuperMode for K550/W610
Download Version C
original camdriver0.dat for those who don't like this camdriver or want to use others.
+ Features:
- Manual settings:
EV
ISO
Shutter Speed
Focus
Saturation
Contrast
Color Correction
- Preview zoom
+ How to upload camdriver0.dat and *.lng to phone:
- download XS++ 3.1.
- shut down your phone.
- run XS++, click on 'Connect', put USB cable to your PC, while pressing 'C' key on your phone, put the other side of cable to your phone, wait XS++ recognize your phone.
- click on FSX™ radio button, click on 'Start FSX', wait a minute or two.
- find IFS/SETTINGS/CAMERA, drag and drop camdriver0.dat to right window.
- find TPA/PRESET/SYSTEM/LANGUAGE, drag and drop *.lng to right window.
- in XS++ click on 'Shutdown', then click on 'Yes'.
- close XS++ and disconnect your phone.
+ How to use this camdriver:
choose appropriate Scene, switch Preview zoom to On if you want. with 7 button choose EV. with 4 button choose focus type, if you want to use manual focus, choose ∞. now with 7 button you can choose settings and with joypad you can change its value.
- Changing EV: in menu choose Manual settings, choose EV, or with 7 button choose EV, with joypad you can change its value.
- Changing ISO: in menu choose Manual settings, choose ISO, or with 7 button choose ISO, with joypad you can change its value.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent ISO | 100 | 125 | 160 | 200 | 250 | 320 | Auto | 400 | 500 | 640 | 800 | 1000 | 1000 |
- Changing Shutter Speed: in menu choose Manual settings, choose Shutter Speed, or with 7 button choose Shutter Speed, with joypad you can change its value.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent Shutter Speed | | Scene auto | Auto | | Scene Twilight | 1/100 | 1/80 | 1/60 | 1/40 | 1/20 | 1/15 | Auto | 1/8 | 1/4 | 1/2 | 3/4 | 1 | 2 | | Scene Others | 1/5000 | 1/3200 | 1/2000 | 1/1000 | 1/800 | 1/500 | Auto | 1/400 | 1/200 | 1/100 | 1/80 | 1/60 | 1/40 |
- Changing Focus: in menu choose Manual settings, choose Focus, or with 7 button choose Focus, with joypad you can change its value. you should enable ∞ first.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent Focus | 32 | 30 | 28 | 26 | 24 | 22 | 20 | 18 | 16 | 12 | 8 | 4 | 0 |
- Changing Saturation: in menu choose Manual settings, choose Saturation, or with 7 button choose Saturation, with joypad you can change its value.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent Saturation | -32 | -26 | -21 | -16 | -10 | -5 | 0 | 6 | 11 | 16 | 21 | 27 | 32 |
- Changing Contrast: inmenu choose Manualsettings, choose Contrast, orwith 7 buttonchoose Contrast, withjoypad you can change its value.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent Contrast | -8 | -6 | -5 | -4 | -2 | -1 | 0 | 2 | 3 | 4 | 5 | 7 | 8 |
- Changing Color Correction: inmenu choose Manualsettings, choose Color Correction, orwith 7 buttonchoose Color Correction, withjoypad you can change its value. Color Correction is relative to current white balance.
| Value | -2.0 | -1.7 | -1.3 | -1.0 | -0.7 | -0.3 | 0.0 | +0.3 | +0.7 | +1.0 | +1.3 | +1.7 | +2.0 | | Equivalent CC | Green1 | Green2 | Green3 | Red1 | Red2 | Red3 | Off | Yellow1 | Yellow2 | Yellow3 | Blue1 | Blue2 | Blue3 |
+ Credits:
SPU, Raiderski, SonarikK510, Number1, Brazuka
http://www.esato.com/board/viewtopic.php?topic=166481&forum=17
[ This Message was edited by: sadeghi85 on 2008-03-28 09:29 ] |
|
|
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
reserved
[ This Message was edited by: sadeghi85 on 2008-03-28 09:18 ] |
milan91
Joined: Jun 04, 2006
Posts: > 500
From: Europe
PM |
wow  this is great
Can you post some pics ??
|
hgautam
Joined: Jan 29, 2006
Posts: > 500
PM |
WOW!!!!!
I wish SE provided these options as default atleast in their cybersot phone, and even more...
Really great work dude...
Unfortunately, I don't have K550 now... |
Prakash
Joined: Aug 16, 2007
Posts: 40
From: India
PM, WWW
|
Is it possible to have manual shutter speed ?
|
razec
Joined: Aug 20, 2006
Posts: > 500
From: Mars
PM |
Any sample pictures?
10 years at Esato |
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
I didn't change scenes, i just added some manual settings and i wanted to share it so there is no need for pics.... but well some pics:
and manual settings is really useful when you want to edit your pic with software. then a bit underexposed pic is better than high ISO, high noise pic.
original
processed
[ This Message was edited by: sadeghi85 on 2008-03-24 17:12 ] |
razec
Joined: Aug 20, 2006
Posts: > 500
From: Mars
PM |
The intel logo looks sharp. can we see it in full res crop?
10 years at Esato |
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
100% crop by 'Crop and Straighten Photos' photoshop command.
too much sharpening (+2.0)  |
razec
Joined: Aug 20, 2006
Posts: > 500
From: Mars
PM |
Wow  sharp lowlight pic!. it's a good camdriver
10 years at Esato |
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
salamat kabayan
but it seems no K550/W610 owner like this camdriver, maybe because apart from manual settings, it's exactly the original camdriver
with these settings, there is no need to change scenes in camdriver, we have all we need in menu!!!
[ This Message was edited by: sadeghi85 on 2008-03-12 12:07 ] |
brazzuka's
Joined: Nov 14, 2007
Posts: > 500
From: South World-Antartida-Sweden
PM, WWW
|
On 2008-03-12 13:03:00, sadeghi85 wrote:
salamat kabayan
but it seems no K550/W610 owner like this camdriver, maybe because apart from manual settings, it's exactly the original camdriver
with these settings, there is no need to change scenes in camdriver, we have all we need in menu!!!
[ This Message was edited by: sadeghi85 on 2008-03-12 12:07 ]
Nice interface menu but someone already applied settings in the driver?
And other languages menu? Would be easier to describe the lines changed so that everyone can learn and switch to their language?
|
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
On 2008-03-12 13:29:33, brazuka wrote:
And other languages menu? Would be easier to describe the lines changed so that everyone can learn and switch to their language?
Well, by using LngEditor we can change menu. now every one can translate changes to EN.lng, to his/her own language by editing appropriate *.lng file that can be found in TPA/PRESET/SYSTEM/LANGUAGE.
[ This Message was edited by: sadeghi85 on 2008-03-24 17:09 ] |
brazzuka's
Joined: Nov 14, 2007
Posts: > 500
From: South World-Antartida-Sweden
PM, WWW
|
@sadeghi85
yep i know sade.
but the settings will be in the driver k550/w610, the option sharpness is good??? humm Perhaps the white balance RGB option it would be better it might be a good option good well depends on the settings applied in driver.
[ This Message was edited by: brazuka on 2008-03-17 10:54 ] |
sadeghi85
Joined: Oct 13, 2007
Posts: 341
PM |
aah thanks brazuka
i'll think about white balance and focus.
[ This Message was edited by: sadeghi85 on 2008-03-24 20:19 ] |
|
|
Posted: 2008-03-08 14:26
